Hitachi Cooling & Heating / SERIES OVERVIEW

Hitachi Absorption Chillers & Chiller-Heaters

Water / lithium-bromide absorption chiller / chiller-heater

Brand
Hitachi Cooling & Heating
Series
Absorption
Equipment category
Chillers
Request a QuoteRequest Technical Information
Hitachi gas-fired absorption chiller configuration
Representative image. Appearance may vary by configuration.

Product overview

Hitachi absorption equipment uses a water / lithium-bromide cycle driven by gas or steam. This page separates gas-fired and steam-fired tables, standard and high-efficiency configurations, enlarged-heating variants and three-use equipment. Compare each heat-source configuration on its own terms: steam consumption and fuel heat input are different from the electrical input of a compressor chiller.

Key technical specifications

Match the complete model and configuration to your design duty. Compare ratings only at the stated water and ambient conditions; then send the model reference, quantity and project requirements for review.

Scroll each table horizontally to compare all columns. Model references remain visible as you scroll.

Gas-fired standard efficiency — enlarged heating

Water / lithium-bromide absorption equipment; heat source as named.

Gas-fired standard efficiency — enlarged heating. Water / lithium-bromide absorption equipment; heat source as named.
Model referenceCooling capacity(kW)Cooling capacity (printed)(USRT)Chilled-water entering temperature(°C)Chilled-water leaving temperature(°C)Chilled-water flow(m³/h)Heating capacity(kW)
HAU-CGH / 450EXSNGRequest a Quote1582450127272.21613
HAU-CGH / 500EXSNGRequest a Quote1758500127302.41936
HAU-CGH / 560EXSNGRequest a Quote1969560127338.71936
HAU-CGH / 600EXSNGRequest a Quote2110600127362.92264
HAU-CGH / 700EXSNGRequest a Quote2461700127423.42264
HAU-CGH / 800EXSNGRequest a Quote2813800127483.82695
HAU-CGH / 900EXSNGRequest a Quote3165900127544.33256
HAU-CGH / 1000EXWSNGRequest a Quote35161000127604.83256
HAU-CGH / 1100EXWSNGRequest a Quote38681100127665.33762
HAU-CGH / 1200EXWSNGRequest a Quote42201200127725.83762
HAU-CGH / 1300EXW3SNGRequest a Quote45711300127786.24275
HAU-CGH / 1400EXW3SNGRequest a Quote49231400127846.74275
HAU-CGH / 1500EXW3SNGRequest a Quote52741500127907.24750
HAU-CGH / 1600EXW3SNGRequest a Quote5626160012.57879.74750
  • These are the printed model-header / capacity-suffix references, not fully configured order codes. Gas / steam, standard / high-efficiency and enlarged-heating configurations are kept separate.
  • Cooling: chilled water leaves at 7 °C, entering at 12 °C except the listed 1,600 USRT selection at 12.5 °C; condenser water entering / leaving 32 / 37 °C. Printed USRT and kW values are retained; no conversion is substituted.
  • Auxiliary supply AC 380 V / 50 Hz / 3 phase. Chilled-water and condenser-water maximum operating pressure 1.0 MPa. Water / lithium-bromide absorption cycle; no electric compressor rating is assigned.
  • The enlarged-heating table rates leaving hot water at 60 °C; entering hot water varies by model. Heating capacity is the separately printed value, not inferred from cooling capacity.
  • Manufacturer reference: Z0050065-251030; physical PDF page 8.

Gas-fired high efficiency

Water / lithium-bromide absorption equipment; heat source as named.

Gas-fired high efficiency. Water / lithium-bromide absorption equipment; heat source as named.
Model referenceCooling capacity(kW)Cooling capacity (printed)(USRT)Chilled-water entering temperature(°C)Chilled-water leaving temperature(°C)Chilled-water flow(m³/h)
HAU-CGN / 180EXHNGRequest a Quote633180127108.9
HAU-CGN / 240EXHNGRequest a Quote844240127145.2
HAU-CGN / 300EXHNGRequest a Quote1055300127181.4
HAU-CGN / 360EXHNGRequest a Quote1266360127217.7
HAU-CGN / 400EXHNGRequest a Quote1407400127241.9
HAU-CGN / 450EXHNGRequest a Quote1582450127272.2
HAU-CGN / 500EXHNGRequest a Quote1758500127302.4
HAU-CGN / 560EXHNGRequest a Quote1969560127338.7
HAU-CGN / 600EXHNGRequest a Quote2110600127362.9
HAU-CGN / 700EXHNGRequest a Quote2461700127423.4
HAU-CGN / 800EXHNGRequest a Quote2813800127483.8
HAU-CGN / 900EXHNGRequest a Quote3165900127544.3
HAU-CGN / 1000EXWHNGRequest a Quote35161000127604.8
HAU-CGN / 1100EXWHNGRequest a Quote38681100127665.3
HAU-CGN / 1200EXWHNGRequest a Quote42201200127725.8
HAU-CGN / 1300EXW3HNGRequest a Quote45711300127786.2
HAU-CGN / 1400EXW3HNGRequest a Quote49231400127846.7
HAU-CGN / 1500EXW3HNGRequest a Quote52741500127907.2
HAU-CGN / 1600EXW3HNGRequest a Quote5626160012.57879.7
  • These are the printed model-header / capacity-suffix references, not fully configured order codes. Gas / steam, standard / high-efficiency and enlarged-heating configurations are kept separate.
  • Cooling: chilled water leaves at 7 °C, entering at 12 °C except the listed 1,600 USRT selection at 12.5 °C; condenser water entering / leaving 32 / 37 °C. Printed USRT and kW values are retained; no conversion is substituted.
  • Auxiliary supply AC 380 V / 50 Hz / 3 phase. Chilled-water and condenser-water maximum operating pressure 1.0 MPa. Water / lithium-bromide absorption cycle; no electric compressor rating is assigned.
  • Manufacturer reference: Z0050065-251030; physical PDF page 8.

Gas-fired high efficiency — enlarged heating

Water / lithium-bromide absorption equipment; heat source as named.

Gas-fired high efficiency — enlarged heating. Water / lithium-bromide absorption equipment; heat source as named.
Model referenceCooling capacity(kW)Cooling capacity (printed)(USRT)Chilled-water entering temperature(°C)Chilled-water leaving temperature(°C)Chilled-water flow(m³/h)Heating capacity(kW)
HAU-CGH / 450EXHNGRequest a Quote1582450127272.21613
HAU-CGH / 500EXHNGRequest a Quote1758500127302.41936
HAU-CGH / 560EXHNGRequest a Quote1969560127338.71936
HAU-CGH / 600EXHNGRequest a Quote2110600127362.92264
HAU-CGH / 700EXHNGRequest a Quote2461700127423.42264
HAU-CGH / 800EXHNGRequest a Quote2813800127483.82695
HAU-CGH / 900EXHNGRequest a Quote3165900127544.33256
HAU-CGH / 1000EXWHNGRequest a Quote35161000127604.83256
HAU-CGH / 1100EXWHNGRequest a Quote38681100127665.33762
HAU-CGH / 1200EXWHNGRequest a Quote42201200127725.83762
HAU-CGH / 1300EXW3HNGRequest a Quote45711300127786.24275
HAU-CGH / 1400EXW3HNGRequest a Quote49231400127846.74275
HAU-CGH / 1500EXW3HNGRequest a Quote52741500127907.24750
HAU-CGH / 1600EXW3HNGRequest a Quote5626160012.57879.74750
  • These are the printed model-header / capacity-suffix references, not fully configured order codes. Gas / steam, standard / high-efficiency and enlarged-heating configurations are kept separate.
  • Cooling: chilled water leaves at 7 °C, entering at 12 °C except the listed 1,600 USRT selection at 12.5 °C; condenser water entering / leaving 32 / 37 °C. Printed USRT and kW values are retained; no conversion is substituted.
  • Auxiliary supply AC 380 V / 50 Hz / 3 phase. Chilled-water and condenser-water maximum operating pressure 1.0 MPa. Water / lithium-bromide absorption cycle; no electric compressor rating is assigned.
  • The enlarged-heating table rates leaving hot water at 60 °C; entering hot water varies by model. Heating capacity is the separately printed value, not inferred from cooling capacity.
  • Manufacturer reference: Z0050065-251030; physical PDF page 9.

Steam-fired standard efficiency

Water / lithium-bromide absorption equipment; heat source as named.

Steam-fired standard efficiency. Water / lithium-bromide absorption equipment; heat source as named.
Model referenceCooling capacity(kW)Cooling capacity (printed)(USRT)Chilled-water entering temperature(°C)Chilled-water leaving temperature(°C)Chilled-water flow(m³/h)Steam consumption(kg/h)
HAU-CW / 180EXSNGRequest a Quote633180127108.9684
HAU-CW / 240EXSNGRequest a Quote844240127145.2912
HAU-CW / 300EXSNGRequest a Quote1055300127181.41140
HAU-CW / 360EXSNGRequest a Quote1266360127217.71368
HAU-CW / 400EXSNGRequest a Quote1407400127241.91520
HAU-CW / 450EXSNGRequest a Quote1582450127272.21710
HAU-CW / 500EXSNGRequest a Quote1758500127302.41900
HAU-CW / 560EXSNGRequest a Quote1969560127338.72128
HAU-CW / 600EXSNGRequest a Quote2110600127362.92280
HAU-CW / 700EXSNGRequest a Quote2461700127423.42660
HAU-CW / 800EXSNGRequest a Quote2813800127483.83040
HAU-CW / 900EXSNGRequest a Quote3165900127544.33420
HAU-CW / 1000EXWSNGRequest a Quote35161000127604.83800
HAU-CW / 1100EXWSNGRequest a Quote38681100127665.34180
HAU-CW / 1200EXWSNGRequest a Quote42201200127725.84560
HAU-CW / 1300EXW3SNGRequest a Quote45711300127786.24940
HAU-CW / 1400EXW3SNGRequest a Quote49231400127846.75320
HAU-CW / 1500EXW3SNGRequest a Quote52741500127907.25700
HAU-CW / 1600EXW3SNGRequest a Quote5626160012.57879.76080
  • These are the printed model-header / capacity-suffix references, not fully configured order codes. Gas / steam, standard / high-efficiency and enlarged-heating configurations are kept separate.
  • Cooling: chilled water leaves at 7 °C, entering at 12 °C except the listed 1,600 USRT selection at 12.5 °C; condenser water entering / leaving 32 / 37 °C. Printed USRT and kW values are retained; no conversion is substituted.
  • Auxiliary supply AC 380 V / 50 Hz / 3 phase. Chilled-water and condenser-water maximum operating pressure 1.0 MPa. Water / lithium-bromide absorption cycle; no electric compressor rating is assigned.
  • Steam inlet pressure: 0.8 MPa gauge. Steam consumption belongs to this efficiency configuration; it is not electrical input or an electric-chiller COP.
  • Manufacturer reference: Z0050065-251030; physical PDF page 9.

Steam-fired high efficiency

Water / lithium-bromide absorption equipment; heat source as named.

Steam-fired high efficiency. Water / lithium-bromide absorption equipment; heat source as named.
Model referenceCooling capacity(kW)Cooling capacity (printed)(USRT)Chilled-water entering temperature(°C)Chilled-water leaving temperature(°C)Chilled-water flow(m³/h)Steam consumption(kg/h)
HAU-CW / 180EXNGRequest a Quote633180127108.9648
HAU-CW / 240EXNGRequest a Quote844240127145.2864
HAU-CW / 300EXNGRequest a Quote1055300127181.41080
HAU-CW / 360EXNGRequest a Quote1266360127217.71296
HAU-CW / 400EXNGRequest a Quote1407400127241.91440
HAU-CW / 450EXNGRequest a Quote1582450127272.21620
HAU-CW / 500EXNGRequest a Quote1758500127302.41800
HAU-CW / 560EXNGRequest a Quote1969560127338.72016
HAU-CW / 600EXNGRequest a Quote2110600127362.92160
HAU-CW / 700EXNGRequest a Quote2461700127423.42520
HAU-CW / 800EXNGRequest a Quote2813800127483.82880
HAU-CW / 900EXNGRequest a Quote3165900127544.33240
HAU-CW / 1000EXWNGRequest a Quote35161000127604.83600
HAU-CW / 1100EXWNGRequest a Quote38681100127665.33960
HAU-CW / 1200EXWNGRequest a Quote42201200127725.84320
HAU-CW / 1300EXW3NGRequest a Quote45711300127786.24680
HAU-CW / 1400EXW3NGRequest a Quote49231400127846.75040
HAU-CW / 1500EXW3NGRequest a Quote52741500127907.25400
HAU-CW / 1600EXW3NGRequest a Quote5626160012.57879.75760
  • These are the printed model-header / capacity-suffix references, not fully configured order codes. Gas / steam, standard / high-efficiency and enlarged-heating configurations are kept separate.
  • Cooling: chilled water leaves at 7 °C, entering at 12 °C except the listed 1,600 USRT selection at 12.5 °C; condenser water entering / leaving 32 / 37 °C. Printed USRT and kW values are retained; no conversion is substituted.
  • Auxiliary supply AC 380 V / 50 Hz / 3 phase. Chilled-water and condenser-water maximum operating pressure 1.0 MPa. Water / lithium-bromide absorption cycle; no electric compressor rating is assigned.
  • Steam inlet pressure: 0.8 MPa gauge. Steam consumption belongs to this efficiency configuration; it is not electrical input or an electric-chiller COP.
  • Manufacturer reference: Z0050065-251030; physical PDF page 10.

Gas-fired three-use configuration — cooling references

Separate three-use chiller / heater / domestic-hot-water configuration.

Gas-fired three-use configuration — cooling references. Separate three-use chiller / heater / domestic-hot-water configuration.
Model referenceCooling capacity(kW)Cooling capacity (printed)(USRT)Chilled-water flow(m³/h)
HAU-CG / N180EXSNGLHRequest a Quote633180108.9
HAU-CG / N240EXSNGLHRequest a Quote844240145.2
HAU-CG / N300EXSNGLHRequest a Quote1055300181.4
HAU-CG / N360EXSNGLHRequest a Quote1266360217.7
HAU-CG / N400EXSNGLHRequest a Quote1407400241.9
HAU-CG / H450EXSNGLHRequest a Quote1582450272.2
HAU-CG / H500EXSNGLHRequest a Quote1758500302.4
HAU-CG / H560EXSNGLHRequest a Quote1969560338.7
HAU-CG / H600EXSNGLHRequest a Quote2110600362.9
HAU-CG / H700EXSNGLHRequest a Quote2461700423.4
HAU-CG / H800EXSNGLHRequest a Quote2813800483.8
HAU-CG / H900EXSNGLHRequest a Quote3165900544.3
HAU-CG / H1000EXW1NGLHRequest a Quote35161000604.8
  • Printed model-header / suffix references only, not complete order codes; final hot-water and domestic-water configuration requires manufacturer selection.
  • Cooling water circuit: chilled water 12 / 7 °C; condenser water 32 / 37 °C. Heating water entering / leaving: 56.4 / 60.0 °C; domestic hot water entering / leaving: 45 / 60 °C. Duties and hydraulic circuits must be selected separately.
  • Auxiliary supply AC 380 V / 50 Hz / 3 phase. The three-use table is not merged into the standard or enlarged-heating tables.
  • Manufacturer reference: Z0050065-251030; physical PDF page 10.

Key configuration options

  • Gas-fired CGN and enlarged-heating CGH references have separate tables; CW identifies the steam-fired configuration in the reviewed brochure.
  • Model references retain the printed header and suffix separately. Final order codes also depend on the selected hydraulic arrangement, heat source and optional equipment.
  • Three-use configurations add a separate domestic-hot-water circuit. Cooling, space-heating and domestic-water duties require individual selection.
  • Confirm available gas or steam conditions, condenser-water duty, water-side pressure and plant-room access before comparing selections.

Applications

  • Large commercial or industrial chilled-water projects with an appropriate gas or steam heat source.
  • Projects requiring separately selected chilled-water, heating-water or domestic-water equipment duties.

Information for equipment selection

  • Gas-fired or steam-fired duty, required configuration and cooling / heating loads.
  • Gas supply or steam pressure / availability, water temperatures, flows and operating schedule.
  • Water-side pressure, auxiliary power, installation access, project location and destination country.

Application suitability requires a review of the project requirements and selected model.

Project equipment procurement

Delta M&E reviews equipment requirements, manufacturer selections and supply arrangements for each inquiry. Send your BOQ or equipment schedule to discuss the required model, documentation and destination.
